A latch is a wear part. When it bends, sticks or stops closing fully, the hook is out of service until it is replaced.
SS-4055 kits fit the older latch pattern. Check which your hooks take before ordering — the two are not interchangeable.
Features
- Stainless steel construction with cadmium plated steel nuts.
- Shipped packaged and unassembled.
- Instructions included for easy field assembly. Hook Size (t) Hook ID Code SS-4055 Stock No. Carbon Alloy Bronze 3/4 1 .5 D 1090027 1 1-1/2 .6 F 1090045 1-1/2 - 2 2 - 3 1.0 - 1.4 G / H 1090063 3 4-1/2 2.0 I 1090081 5 7 3.5 J 1090107 7-1/2 - 10 11 - 15 5.0 - 6.5 K / L 1090125 15 22 10.0 N 1090143 20 30 -- O 1090161 25 - 30 37 - 45 -- P / S 1090189 40 60 -- T 1090205 SS-4055 REPLACEMENT LATCH KITS Copyright © 2016 The Crosby Group LLC All Rights Reserved.
Specifications
Tap Add on any line to build a quote list.
| Carbon | Hook Size (t) Alloy | Bronze | Hook ID Code | SS-4055 Stock No. | Quote |
|---|---|---|---|---|---|
| 3/4 | 1 | .5 | D | 1090027 | |
| 1 | 1-1/2 | .6 | F | 1090045 | |
| 1-1/2 - 2 | 2 - 3 | 1.0 - 1.4 | G / H | 1090063 | |
| 3 | 4-1/2 | 2.0 | I | 1090081 | |
| 5 | 7 | 3.5 | J | 1090107 | |
| 7-1/2 - 10 | 11 - 15 | 5.0 - 6.5 | K / L | 1090125 | |
| 15 | 22 | 10.0 | N | 1090143 | |
| 20 | 30 | -- | O | 1090161 | |
| 25 - 30 | 37 - 45 | -- | P / S | 1090189 | |
| 40 | 60 | -- | T | 1090205 | |
| Copyright © 2016 The Crosby | Group LLC All Rights | Reserved | — | — |
