Features
- Rugged, all-steel construction that actually weighs less than comparable aluminum models.
- Get positive braking action with Weston-style load brake incorporating two moisture-resistant brake pads with four braking surfaces. Includes two brake pawls for additional reliability.
- Enjoy protection against dirt and moisture with a totally enclosed brake mechanism.
- Ensure long life with machined, heat-treated, split load double reduction gears.
- Operate in close quarters with short steel handle and 15-degree recovery strokes.
- Patented spring-loaded freewheel mechanism permits easy adjustment of the load chain and safeguards against accidental freewheeling under load.
- Equipped with standard rubber grip for non-slip operation.
- 5-foot lift is standard, 10-, 15- and 20-foot lifts also stocked; nonstandard lifts available as well.
- Grade 100 heat-treated load chain is nickel plated for corrosion resistance.
- Forged and heat-treated alloy steel hooks open slowly without fracturing under excessive loads. Top and bottom hooks rotate 360.˚
Specifications
Tap Add on any line to build a quote list.
| Capacity (tons) | Product Code | Headroom C (in) | Std. Lift (ft) | Pull to Lift Load* (lbs) | Load Chain Dia. (mm) x Chain Fall Lines | Net Weight (lbs) | Weight for Additional One Foot of Lift (lbs) | Quote |
|---|---|---|---|---|---|---|---|---|
| 3/4 | LB008 | 11.0 | 5 | 54 (36) | 5.6 x 1 | 13 | 0.5 | |
| 1 | LB010 | 11.8 | — | 72 (46) | — | 13 | — | |
| 1 1/2 | LB015 | 13.2 | — | 64 (45) | 7.1 x 1 | 18 | 0.7 | |
| 2 | LB020 | 14.8 | — | 59 (42) | 8.8 x 1 | 25 | 1.1 | |
| 2 3/4 | LB028 | — | — | 81 (57) | — | — | — | |
| 3 | LB030 | 15.6 | — | 69 | 10.0 x 1 | 33 | 1.5 | |
| 6 | LB060 | 21.3 | — | 72 | 10.0 x 2 | 57 | 3.2 | |
| 9 | LB090 | 26.8 | — | 78 | 10.0 x 3 | 88 | 4.7 |
