Crane Rope
Eight strands laid around a core, in regular lay, normally built as either 19 Seale or 25 Filler Wire. The size relationship between the strands and the core is what gives an 8×19 more bendability than a six-strand rope of the same diameter.
It carries more crushing resistance and a higher minimum breaking force than a 19×7, but less rotation resistance. Use it in multi-part reeving where limited rotation resistance is what the job calls for — not where a single part is lifting a load free on the hook.
Features
- Increased bendability
- Crush resistant
- Fatigue resistant
- No swivel
- Right lay
- Lubricated
- Multi layer spooling
Specifications
Cut to length from stock in Hatfield. Call for reel quantities and lead times.
| Rope Diameter (in.) | Approximate Weight per Foot (lbs.) | Nominal Breaking Strength (tons) |
|---|---|---|
| 7/16 | .36 | 8.97 |
| 1/2 | .47 | 11.6 |
| 9/16 | .60 | 14.7 |
| 5/8 | .73 | 18.1 |
| 3/4 | 1.06 | 25.9 |
| 7/8 | 1.44 | 35.0 |
| 1 | 1.88 | 45.5 |
| 1 1/8 | 2.39 | 57.3 |
| 1 1/4 | 2.94 | 70.5 |
Standard constructions are 19 Seale and 25 Filler Wire. See 6×19 class for what those construction names mean.
