Endless Round Slings
Features
- Up to 50% lighter than conventional round slings for even better manual handling
- Up to 50% slimmer than conventional round slings
- Can be laid against tighter edge radii than conventional PES slings
- Shackle and hardware interface is therefore less crowded
- Variable load bearing point for more even wear
- Ideal for choke lifting cylindrical objects without creasing
- Less creasing means less wear
- Lifts smooth objects without damage
- High strength to weight ratio
- Reinforced high performance woven cover
Specifications
Tap Add on any line to build a quote list.
| Part Number | Vertical Capacity (lbs.) | Choker Capacity (lbs.) | Basket Capacity (lbs.) 90˚ | Basket Capacity (lbs.) 60˚ | Basket Capacity (lbs.) 45˚ | Approx Diameter (in.) | Approx Weight per foot (lbs.) | Quote |
|---|---|---|---|---|---|---|---|---|
| RCHPE20 | 20,000 | 16,000 | 40,000 | 34,640 | 28,280 | 1.85 | 0.6 | |
| RCHPE30 | 30,000 | 24,000 | 60,000 | 51,960 | 42,420 | 2.2 | .85 | |
| RCHPE40 | 40,000 | 32,000 | 80,000 | 69,280 | 56,560 | 2.70 | 1.0 | |
| RCHPE50 | 50,000 | 40,000 | 100,000 | 86,600 | 70,700 | 2.80 | 1.15 | |
| RCHPE60 | 60,000 | 48,000 | 120,000 | 103,920 | 84,840 | 3 | 1.30 | |
| RCHPE80 | 80,000 | 64,000 | 160,000 | 138,560 | 113,120 | 3.70 | 1.60 | |
| RCHPE100 | 100,000 | 80,000 | 200,000 | 173,200 | 141,400 | 4 | 1.8 | |
| RCHPE125 | 125,000 | 100,000 | 250,000 | 216,500 | 176,750 | 5.10 | 2.5 | |
| RCHPE150 | 150,000 | 120,000 | 300,000 | 259,800 | 212,100 | 6.80 | 3.3 | |
| RCHPE200 | 200,000 | 160,000 | 400,000 | 346,400 | 282,800 | 8 | 5.25 | |
| RCHPE250 | 250,000 | 200,000 | 500,000 | 433,000 | 353,500 | 9.10 | 5.85 | |
| RCHPE300 | 300,000 | 240,000 | 600,000 | 519,600 | 424,200 | 10.55 | 7.0 |
Need a price or a lead time?
Most stocked items ship the same day from Hatfield. Call and we’ll confirm what’s on the shelf.
