Galvanized Aircraft Cable
7×7 cable is seven strands of seven wires — forty-nine wires in all. That is fewer and larger wires than a 7×19 of the same diameter, so it is stiffer and holds up better to abrasion, and it is made in the small diameters a 7×19 is not.
Use it on pulleys and for general small-diameter work where you need something below the sizes 7×19 is built in.
Features
- Conforms to U.S. Federal Specification RR-W-410H
- Small diameter 7x7 cable is great for use on pulleys and general use when diameters are needed smaller than available in 7x19 construction
- Zinc (galvanized) coated steel cable is the most common type of cable. It offers moderate corrosion resistance, and remains ductile over long periods when running over sheaves. Galvanized cable is stronger than stainless steel cable.
- Can be cut in custom lengths from 1 ft to 5,000 ft
Specifications
Tap Add on any line to build a quote list, or call for a custom cut length.
| Stock Number | Rope Diameter (in.) | Length on Reel (ft.) | Approximate Weight Per Reel (lbs.) | Nominal Breaking Strength (lbs.) | Quote |
|---|---|---|---|---|---|
| 300-22 | 1/16 | 250 | 2 | 480 | |
| 300-24 | 1/16 | 500 | 4 | 480 | |
| 300-26 | 1/16 | 1000 | 8 | 480 | |
| 300-32 | 3/32 | 250 | 4 | 920 | |
| 300-34 | 3/32 | 500 | 8 | 920 | |
| 300-36 | 3/32 | 1000 | 16 | 920 | |
| 300-42 | 1/8 | 250 | 7 | 1,700 | |
| 300-44 | 1/8 | 500 | 14 | 1,700 | |
| 300-46 | 1/8 | 1000 | 28 | 1,700 |
